LC — Compact Welded Console
Compact welded console, no protrusion — for reduced transit-space plant.
Compact control console, completely welded, with no protrusion — suitable for plant with reduced transit space. Features an 18° tilt desk, hinged and openable from inside, a cable-entry flange on the bottom, and a 2 mm FeZn fixed internal plate. Plinth application configuration.
Key Features
- ▸Compact, completely welded console — no protrusion
- ▸18° tilt desk, hinged and openable from inside
- ▸Suitable for reduced transit-space plant
- ▸2 mm FeZn fixed internal plate, cable-entry flange on the bottom
- ▸Plinth application configuration
IP Rating
IP66
Material
1.5 mm carbon steel sheet · RAL 7035 textured (body) + RAL 7009 textured (plinth) + RAL 6033 textured (profiles)
IK Rating
IK10
Mounting
Plinth-mount (H100 / H200)
Standards
Certifications & Compliance
- ▸IP66 (CEI EN 62208 / CEI EN 60529, internal use)
- ▸IK10 (CEI EN 62208 / CEI EN 62262)
Models & Specifications
Available Models
| Box SKU | Dimensions (mm) H × W × D | Dimensions (in) H × W × D | Plinth H100 | Plinth H200 | Quote |
|---|---|---|---|---|---|
| LC6113.35 | 1143 × 610 × 305 | 45 × 24 × 12 | LC612 | LC622 | |
| LC8113.35 | 1143 × 787 × 305 | 45 × 31 × 12 | LC812 | LC822 | |
| LC10113.35 | 1143 × 991 × 305 | 45 × 39 × 12 | LC1012 | LC1022 | |
| LC12113.35 | 1143 × 1194 × 305 | 45 × 47 × 12 | LC1212 | LC1222 | |
| LC16113.35 | 1143 × 1600 × 305 | 45 × 63 × 12 | LC1612 | LC1622 |
Catalog source: Tecnomatic Enclosures Brochure (2026) p 37. Custom sizes, finishes, and configurations on request.
LC6113 / LC8113 are single-door; LC10113 / LC12113 / LC16113 are two-door. Completely welded with no protrusion — suitable for reduced transit-space plant. Add suffix .35 for RAL 7035 textured finish. Dimensions converted from nominal inches (1 in = 25.4 mm).
Use Cases
Typical Applications
Tight-aisle plant
Consoles for narrow-transit production areas with limited clearance.
Operator control desks
Compact seated operator stations on the floor.
Machine-side HMI
Local HMI in space-constrained machine cells.
LC6113 / LC8113 are single-door; LC10113 / LC12113 / LC16113 are two-door. Completely welded with no protrusion — suitable for reduced transit-space plant. Add suffix .35 for RAL 7035 textured finish. Dimensions converted from nominal inches (1 in = 25.4 mm).
Enclosures for indoor use only — contact our technical department for outdoor use.
